FuseBox MAFDD060630B AFDD RCBO B 6A 30mA

FuseBox MAFDD060630B AFDD RCBO B 6A 30mA | 1-Module Arc Fault Detection Device with 6kA Breaking Capacity

Improve electrical safety and circuit protection with the FuseBox MAFDD060630B AFDD RCBO B 6A 30mA. This compact 1-module device combines three essential safety functions into a single unit: an Arc Fault Detection Device (AFDD), a Miniature Circuit Breaker (MCB), and a Residual Current Device (RCD).

Technical Specifications at a Glance:

• Model: FuseBox MAFDD060630B
• Type: Combined AFDD + RCBO (Arc Fault Detection Device with Overcurrent and Residual Current Protection)
• Rated Current: 6A
• Tripping Characteristic: B Curve
• RCD Type: Type A (AC and Pulsating DC Sensitive)
• Residual Current Sensitivity: 30mA
• Breaking Capacity: 6kA
• Number of Poles: 1P+N (Switched Line and Neutral)
• Width: 1 Module (17.8mm)
• Height: 100mm
• Depth: 75.6mm
• Voltage Rating: 230V
• Mounting: 35mm DIN Rail
• Terminal Capacity: 10mm² - 16mm²
• Standards: BS EN 62606, IEC 61009-1
• Application: Residential and Commercial Installations
