Lewden RCBO-10/30/1M/C RCBO 10A 30mA

Lewden RCBO-10/30/1M/C RCBO 10A 30mA | 1 Module C Type with 10kA Breaking Capacity

Enhance circuit protection and safety with the Lewden RCBO-10/30/1M/C RCBO 10A 30mA. This compact single-pole residual current circuit breaker with integral overcurrent protection combines RCD and MCB functionality in a single module. Features a C-type tripping curve, 10kA breaking capacity, and Type A RCD protection against earth leakage, overloads, and short circuits.

Technical Specifications at a Glance:

• Model: Lewden RCBO-10/30/1M/C
• Type: RCBO (Residual Current Circuit Breaker with Overcurrent Protection)
• Rated Current: 10A
• Tripping Curve: Type C
• RCD Type: Type A
• Residual Current Sensitivity: 30mA
• Breaking Capacity: 10kA
• Number of Poles: Single Pole
• Width: 1 Module (18mm)
• Rated Voltage: 230V
• Mounting: DIN Rail
• Cable Size: 1-16mm²
• Dimensions: 126.4mm x 18mm x 76.1mm
