Lewden RCBO-20/30/1M/C RCBO 20A 30mA

Lewden RCBO-20/30/1M/C RCBO 20A 30mA | 1 Module C Type with 10kA Breaking Capacity

Elevate circuit protection and safety with the Lewden RCBO-20/30/1M/C RCBO 20A 30mA. This compact single-pole residual current circuit breaker with integral overcurrent protection combines RCD and MCB functionality in a single module.

Combined RCD & MCB Protection

This RCBO integrates residual current detection and overcurrent protection into one compact unit. As a result, it provides complete protection against earth leakage, overloads, and short circuits. At the same time, its single-module design saves valuable consumer unit space.

C-Type Tripping Curve

The C-curve characteristic tolerates higher inrush currents. This makes it ideal for circuits with inductive loads such as motors, compressors, and lighting with high start-up surges. Consequently, it prevents nuisance tripping while maintaining reliable protection.

Type A RCD Protection

Featuring Type A residual current detection, this RCBO protects against AC and pulsating DC fault currents. This is particularly important for modern electronic equipment and sensitive devices. In short, it delivers enhanced safety for today's electrical installations.

High 10kA Breaking Capacity

With a short-circuit breaking capacity of 10kA, this device offers superior protection against high fault currents. Moreover, it provides a crucial safety margin for demanding commercial and industrial applications.

Space-Saving 1-Module Design

The compact single-module width (18mm) maximises space within the consumer unit. Its 96mm height also increases available wiring space for easier installation. This means more room to work and a tidier final installation.

DIN Rail Mounting & Broad Compatibility

Designed for standard DIN rail installation, this RCBO is fully compatible with Lewden distribution boards. It is also suitable for use in TN-S, TN-C-S, and TT network systems. This versatility makes it a reliable choice for a wide range of electrical setups.

Technical Specifications at a Glance:

• Model: Lewden RCBO-20/30/1M/C
• Type: RCBO (Residual Current Circuit Breaker with Overcurrent Protection)
• Rated Current: 20A
• Tripping Curve: Type C
• RCD Type: Type A
• Residual Current Sensitivity: 30mA
• Breaking Capacity: 10kA
• Single Pole
• Width: 1 Module (18mm)
• Rated Voltage: 230V
• Mounting: DIN Rail
• Cable Size: 1-16mm²
• Dimensions: 126.4mm x 18mm x 76.1mm (HWD)
